Comprehensive and Detailed Step-by-Step Explanation:

Routing Table Structure:

Routers maintain a local core routing table and separate protocol routing tables for OSPF, BGP, etc.

The local core routing table stores optimal routes selected based on metrics, protocol preferences, and administrative distances.

Fields in the Core Routing Table:

Destination Address (A): Indicates the destination network or host.

Routing Protocol Preference (B): Determines the priority of routing protocols (e.g., OSPF > RIP).

Routing Protocol (D): Specifies the protocol (e.g., OSPF, BGP) that contributed the route.

Inbound Interface: This is stored in the protocol-specific routing table but not in the local core table.

References:

HCIA-Datacom Study Guide, Chapter: Routing Table Management

Huawei Routing Fundamentals

 ACL Modification

Named ACLs can be modified after their creation. Unlike numbered ACLs, named ACLs provide greater flexibility for editing individual rules without deleting the entire ACL.

Therefore, the statement is incorrect.

 HCIP-Datacom-Core Reference

The flexibility and editability of named ACLs are discussed in the ACL configuration sections​​.

Comprehensive and Detailed Step-by-Step Explanation:

Understanding the ACL Configuration:

ACL Number: 3001 is an advanced ACL.

Rule Description: The rule permits ICMP packets with the following criteria:

Source IP: 192.168.1.3 (host-specific).

Destination IP: 192.168.2.0/24 (entire subnet).

Analysis of Each Option:

Option A: True. ICMP packets from 192.168.1.3 to 192.168.2.200 (within the subnet) are permitted.

Option B: True. Packets from 192.168.1.2 (not matching the source) are denied by default.

Option C: False. The ACL only permits ICMP packets, not general IP packets.

Option D: True. The ACL is identified by the number 3001.

References:

HCIA-Datacom Study Guide, Chapter: ACL Filtering Rules

Huawei Advanced ACL Configuration

Comprehensive and Detailed in-depth Step-by-Step Explanation:In IS-IS, the interface cost is a metric used to determine the best path to a destination. Lower-cost paths are preferred over higher-cost paths. By default, IS-IS interface costs can range from 1 to 63.

Default Cost Range:

IS-IS allows the configuration of interface costs within the range of 1–63 by default. This range is sufficient for most networks.

Maximum Configurable Cost:

The maximum value that can be configured by default is 63. If there is a requirement for a higher cost range, the metric-style can be changed to wide, which allows the cost range to extend beyond 63.

Option A (67): Incorrect. 67 is not the maximum default value.

Option B (63): Correct. This is the maximum default cost value.

Option C (64): Incorrect. This is beyond the default range.

Option D (68): Incorrect. This is beyond the default range.

References:

Huawei HCIA-Datacom Study Guide, Chapter on "IS-IS Cost and Route Selection".

RFC 5308 – Routing IPv6 with IS-IS.
