CompTIA Updated 220-1101 Exam Questions and Answers by juniper

The fuser is the part of a laser printer that uses heat and pressure to fuse the toner to the paper. If the fuser is defective or not hot enough, the toner may not adhere properly and smear when touched. The duplexing assembly, toner, and transfer belt are not related to this issue.

RFD stands for Radio Frequency Identification, which is a technology that uses radio waves to identify and track objects that have RFID tags attached to them. RFID tags are small devices that store information and can be read by RFID readers without direct contact or line of sight. RFID can be used for inventory management, as it can provide real-time visibility and accuracy of the location, quantity, and status of the items in a warehouse, store, or supply chain .

The next step that the technician should do to troubleshoot the issue is C. Swap the power supply if it is inoperable.

A power supply is a device that converts the alternating current (AC) from the wall outlet into direct current (DC) that the computer components can use. A power supply is essential for the computer to boot and function properly. A faulty or inadequate power supply can cause various issues, such as no power, no display, random shutdowns, or beeping sounds.

In this scenario, the technician is trying to fix a computer that fails to boot even when all the RAM is removed. RAM stands for Random Access Memory, and it is a type of memory that stores data and instructions for the processor to access and process. RAM is also essential for the computer to boot and function properly. A faulty or incompatible RAM can cause various issues, such as no boot, no display, blue screen, or beeping sounds.

One of the basic troubleshooting techniques for a computer that fails to boot is to remove all the RAM modules and try to boot with one module at a time in different slots. This can help to identify if the problem is caused by a bad RAM module or a bad RAM slot. If the computer still fails to boot even when all the RAM is removed, it means that the problem is not related to the RAM, but to another component.

The next step that the technician should do is to swap the power supply if it is inoperable. This means that the technician should test the power supply with a multimeter or a power supply tester, and replace it with a known good one if it is faulty or insufficient. This can help to determine if the problem is caused by a bad power supply or a bad motherboard.

The other options are not the next steps that the technician should do, because they are less likely or less effective. Inspecting the motherboard for swollen capacitors (option A) may be helpful if the problem is caused by a damaged or defective motherboard, but it requires opening the computer case and visually examining the motherboard components. Replacing the CMOS battery (option B) may be necessary if the problem is caused by a low or dead CMOS battery, but it usually affects only the BIOS settings and not the boot process. Checking to see if the HDD power connectors are well seated (option D) may be useful if the problem is caused by a loose or faulty HDD connection, but it usually affects only the data access and not the boot process.

For more information about troubleshooting power supply and boot issues, you can refer to the following web search results: [How to Troubleshoot a Computer That Won’t Turn On], [How to Test a Power Supply Using a Multimeter], [How to Fix a Computer That Shows No Sign of Power], [How to Troubleshoot Beep Codes].

The correct answer is C. Cat 6.

An RJ45 connector is a standard type of physical connector for network cables. RJ45 connectors are used almost exclusively with Ethernet cables and networking1. Ethernet cables are twisted pair cables that carry data signals between devices on a network, such as computers, routers, switches, and servers2.

There are different categories of Ethernet cables, such as Cat 5, Cat 5e, Cat 6, and Cat 7, that have different specifications and performance levels. Cat 6 is one of the most common types of Ethernet cables, which supports data transfer speeds up to 10 Gbps and bandwidth up to 250 MHz3. Cat 6 cables have four pairs of copper wires, each with a plastic insulation and a foil or braided shield. The wires are twisted together to reduce crosstalk and interference4.

To terminate a Cat 6 cable, an administrator needs to use an RJ45 connector that matches the wiring scheme of the cable. There are two common wiring schemes for Ethernet cables: T568A and T568B. The administrator needs to strip the cable jacket, untwist the wires, arrange them in the correct order according to the chosen scheme, trim the excess wire, and insert them into the RJ45 connector. Then, the administrator needs to use a crimping tool to secure the wires and the connector4.

Optical cables are not terminated with RJ45 connectors, but with different types of connectors that can transmit light signals, such as SC, ST, LC, or MTRJ connectors. Optical cables are used for fiber-optic networks that can carry data over long distances at high speeds.

Serial cables are not terminated with RJ45 connectors, but with different types of connectors that can transmit serial data signals, such as DB9, DB25, or DE9 connectors. Serial cables are used for connecting devices that use serial communication protocols, such as modems, printers, scanners, or keyboards.

USB cables are not terminated with RJ45 connectors, but with different types of connectors that can transmit universal serial bus data signals, such as USB-A, USB-B, USB-C, or Micro-USB connectors. USB cables are used for connecting devices that use USB communication protocols, such as flash drives, cameras, mice, or chargers.
