The interfaces are active and respond to ARP for virtual IP as long as the node is the primary or active node in the SRG group. This ensures high availability and proper traffic forwarding. For information, refer to Juniper SRX HA Documentation.

The exhibit shows information about a chassis cluster and itsservices redundancy group (SRG1). Let's analyze the relevant details:

Explanation of Answer B (Backup Node for SRG1):

The exhibit indicates that this SRX device is in thebackuprole for SRG1. Thestatus: BACKUPfield confirms that this device is currently in a standby role and is not the active node for the services redundancy group.

Explanation of Answer A (Interfaces Not Active):

Since the device is in the backup role, the interfacesge-0/0/3.0andge-0/0/4.0will not respond to ARP requests for the virtual IP's MAC address. Only the active node's interfaces respond to ARP requests in a chassis cluster configuration.

Juniper Security Reference:

Chassis Cluster Redundancy Overview: In a chassis cluster, the backup node does not respond to ARP requests for the virtual IP. Only the active node handles such requests to ensure seamless traffic forwarding. Reference: Juniper Chassis Cluster Documentation.

==========

When configuring CoS for an IPsec tunnel with multiple security associations (SAs):

Forwarding Classes Order (Answer C): Both the local and remote SRX devices must have the same forwarding classes defined in the same order to ensure proper traffic classification and SA mapping. If not aligned, traffic classification can fail.

Command Example:

bash

Copy code

set security ipsec vpn vpn_name multi-sa forwarding-classes [class1 class2 ...]

Maximum Forwarding Classes (Answer D): The multi-sa forwarding-classes statement allows up toeightforwarding classes. This is the maximum number of traffic classes that can be differentiated within a single VPN tunnel.

Command Example:

bash

Copy code

set security ipsec vpn vpn_name multi-sa forwarding-classes [class1 class2 class3 class4 class5 class6 class7 class8]

In mixed mode, both Layer 2 and Layer 3 interfaces can be configured to operate within the same security zone, allowing for flexible network segmentation. Additionally, Integrated Routing and Bridging (IRB) interfaces facilitate routing for Layer 2 bridged domains, allowing Layer 2 traffic to be forwarded at Layer 3. For more information on mixed mode and IRB functionality, refer to Juniper's Mixed Mode and IRB Documentation.

Explanation of Answer A (Layer 2 and Layer 3 in Same Zone):

Inmixed modeconfigurations, it is possible to have both Layer 2 and Layer 3 interfaces within the same security zone. This allows for flexible design where different types of traffic can be handled by the same set of security policies.

Explanation of Answer B (IRB Interfaces Can Route Traffic):

IRB (Integrated Routing and Bridging)interfaces are used to route traffic between Layer 2 and Layer 3 domains. They can bridge traffic at Layer 2 and also provide Layer 3 routing capabilities within the same device. This allows for seamless interaction between Layer 2 and Layer 3 traffic in mixed mode.

Step-by-Step Configuration:

Configuring Layer 2 and Layer 3 in the Same Security Zone:

Assign both Layer 2 and Layer 3 interfaces to the same security zone as follows:

bash

Copy code

set security zones security-zone interfaces

Configuring IRB Interface:

To route traffic using the IRB interface:

bash

Copy code

set interfaces irb unit 0 family inet address

set security zones security-zone interfaces irb.0

Juniper Security Reference:

IRB Interface Overview: IRB interfaces allow for both bridging and routing functionalities, making them essential in mixed-mode environments.

Layer 2 and Layer 3 in the Same Zone: This feature provides flexibility in designingnetworks that combine both Layer 2 switching and Layer 3 routing under the same security policies.

==========

The exhibit shows that theGlobal Modeof the SRX Series device is set to "Transparent bridge." This means the device is operating intransparent mode. In this mode, the SRX Series device acts like a Layer 2 bridge, forwarding traffic based on MAC addresses and not performing any Layer 3 (IP) routing or firewalling.

Intransparent mode, the SRX device is effectively invisible to the network at the IP layer, and it bridges traffic between Ethernet interfaces without needing to assign IP addresses to those interfaces. This mode is typically used when you want the SRX to act as a firewall without making any changes to the network's routing configuration.

Key Indicators from the Exhibit:

Global Mode: Transparent bridge: This confirms that the device is configured in transparent mode.

MAC learningandEthernet Switchingoptions are enabled, which aligns with transparent mode functionality where the device learns MAC addresses and switches traffic between VLANs.

Juniper Security Reference:

Transparent Mode Overview: Transparent mode is used to deploy a firewall in Layer 2 mode, where it bridges traffic between VLANs without being an IP routing device. Reference: Juniper Networks Transparent Mode Documentation.
