Microsoft Updated AZ-800 Exam Questions and Answers by jac

Objective:

Configure the DHCP server SRV1 to lease IP addresses only to computers with MAC addresses starting with AABB in a specific range.

Step-by-Step Guide

✅ Step 1: Open DHCP Management Console

Log in to SRV1 with Domain Admin or DHCP Admin privileges.

Open DHCP Manager:

Press Windows + R, type dhcpmgmt.msc, and press Enter.

✅ Step 2: Create a New DHCP Scope

In the DHCP console, expand SRV1.

Right-click IPv4 and select New Scope.

The New Scope Wizard opens.

✅ Step 3: Configure the Scope

Name:

Enter a name (e.g., MAC-Filtered Scope).

Click Next.

IP Address Range:

Start IP: 192.168.1.190

End IP: 192.168.1.200

Subnet mask: as appropriate (e.g., 255.255.255.0).

Click Next.

Add Exclusions:

None needed unless you want to reserve certain addresses.

Click Next.

Lease Duration:

Set as needed, default is usually fine.

Click Next.

Configure DHCP Options:

You can skip or configure as needed (gateway, DNS, etc.).

Click Next.

Activate Scope:

Click Yes to activate it.

✅ Step 4: Configure MAC Address Filtering (Allow List)

In the DHCP console, expand the scope you created.

Right-click Filters under the scope and choose New Filter.

Enter the MAC address pattern to match devices with MAC addresses starting with AABB:

MAC Address: AABB*

Description: e.g., Allow devices starting with AABB.

Click Add.

✅ Step 5: Enable Allow Filters

Right-click Filters under the scope and select Enable.

Ensure that only devices matching the AABB pattern will receive leases.

✅ Step 6: Test and Verify

Use a test client with a MAC address starting with AABB to ensure it receives an IP address in the 192.168.1.190–192.168.1.200 range.

Use ipconfig /renew on the client, or check the DHCP leases in the Address Leases section.

TASK 5

???? Objective:

Configure a Group Policy Preference to create a shortcut to \\srvi.contoso.com\data on the desktop of users in the Server Admins OU.

Step-by-Step Guide: Using Group Policy Preferences to Create a Desktop Shortcut

✅ Step 1: Open Group Policy Management Console (GPMC)

Log in to a DC or a management computer with RSAT installed.

Open Group Policy Management (gpmc.msc).

✅ Step 2: Create a New GPO

In the GPMC console, expand the forest and the domain (e.g., contoso.com).

Right-click the OU named Server Admins and select Create a GPO in this domain, and Link it here.

Name the GPO, e.g., Desktop Shortcut for Server Admins.

✅ Step 3: Edit the GPO

Right-click the newly created GPO and select Edit.

This opens the Group Policy Management Editor.

✅ Step 4: Navigate to User Preferences

In the editor, expand:

User Configuration > Preferences > Windows Settings > Shortcuts.

✅ Step 5: Create the Shortcut

Right-click Shortcuts and select New > Shortcut.

In the New Shortcut Properties window:

Action: Create

Name: Data Folder

Target Type: File System Object

Location: Desktop

Target Path: \\srvi.contoso.com\data

Optionally, set an icon or description if you want.

✅ Step 6: Configure Item-Level Targeting (Optional)

If you want to limit this shortcut strictly to specific users/groups, click the Common tab.

Check Item-level targeting and configure conditions (optional).

For this scenario, linking the GPO to the Server Admins OU is usually sufficient.

✅ Step 7: Close and Update

Close the editor.

In GPMC, ensure the GPO is linked to the Server Admins OU.

Force a Group Policy Update on client computers:

On a client computer:

gpupdate /force

Or wait for the next Group Policy refresh cycle.

✅ Step 8: Verify

Log in as a user in the Server Admins OU.

The shortcut to \\srvi.contoso.com\data should appear on the desktop.
